Instrument Overview
The YGQRD-76X series of 80 GHz radar level transmitters are Frequency Modulated Continuous Wave (FMCW) products operating in the 76-81 GHz band. They support both two-wire and four-wire applications, are available in multiple models, and have a measuring range of up to 120 m.
YGQRD-76X series 80GHz radar level meters are based on self-developed CMOS millimeter-wave RF chips, achieving a more compact RF architecture, higher signal-to-noise ratio, and smaller blind zones. Resistant to steam and dust attenuation of radar echoes; stable measurement is still possible for materials with weak reflection characteristics or low dielectric constants. With a 5GHz operating bandwidth, the product achieves higher measurement resolution and accuracy.
Technical features
| Precision: ±1mm | Range: 0~120m | Transmitting frequency: 76GHz~81GHz |
| Self-developed CMOS millimeter-wave RF chip | Measurement interval as fast as 1000ms | Multiple process connections |
| Bluetooth wireless connectivity | Remote debugging via mobile app | Standard HART 7 protocol communication |
| 5GHz operating bandwidth | Explosion Protection: Ex ia ⅡC T6 Gb/Ex d ⅡC T6 Gb Ex tb ⅢC T80℃ Db | Measuring Range: 10 m; 20 m; 30 m; 60 m; 120 m |
| Multiple display functions (distance units: m, cm, mm, ft, in) | 128x64 dot-matrix display / 4 push-buttons; configurable via PC software or Bluetooth wireless connection. | Installation Method: Threaded or flanged |
Application areas
Petroleum/Petrochemical/Chemical: Liquid level measurement in oil tanks and oil-gas separators. Electric Power/City Gas/Other Public Utilities: Liquid level measurement in boiler feed water, ash slurry tanks, and coal slurry tanks at thermal power plants.
Pulp/Papermaking: Liquid level measurement in pulp tanks, white water tanks, etc.
Iron & Steel / Non-ferrous Metals / Ceramics: Measures slurry level in slurry pools to guide mineral processing; monitors molten metal level to ensure casting process safety. Mechanical Equipment/Shipbuilding: Used for monitoring liquid cargo height in port storage tanks and fuel oil levels in ship fuel tanks.
