Instrument Overview
As High-Temperature Pressure Transmitter, its overall temperature resistance performance has been strictly tested, and it can work stably in the wide temperature range of -40~150℃, and some high-temperature models even support extreme temperature working conditions above 200℃. In the pressure monitoring of the roll cooling system in the hot rolling workshop of iron and steel plants, High-Temperature Pressure Transmitter can resist the influence of the high-temperature environment in the workshop and continuously output accurate pressure signals; in the kiln pressure control of glass manufacturing, it can maintain measurement accuracy in the high-temperature flue gas environment, ensuring stable pressure in the kiln and avoiding quality problems such as bubbles or deformation of glass products.
Whether in high-temperature steam systems, compressor fluctuating working conditions, or high-precision measurement scenarios, this High-precision pressure transmitter integrating Steam Pressure Transmitter 4-20mA, High-Temperature Pressure Transmitter, and Compressor Pressure Transmitter functions can rely on stable performance, precise measurement and convenient operation and maintenance to become a reliable choice for industrial process control.
Technical features
| Precision: ±0.075% | Range: -0.1~40 MPa | Ambient Temperature: -40 to 85°C |
| Turndown Ratio: 60:1 | Standard HART 7 protocol communication | Cable Entry: M20x1.5, 1/2" NPT |
| Bluetooth wireless connectivity | Remote debugging via mobile app | External Terminal: M4 screw |
| Built-in dual-button for quick local adjustment | Comprehensive self-diagnostic functionality | Process Connection: M20x1.5, 1/2" NPT, G1/2, etc |
| Intelligent static pressure and temperature compensation | Backlit LCD display with multiple engineering units (Pa, kPa, MPa, bar, mbar, Torr, atm, inH₂O, inHg, ftH₂O, mmH₂O, mnH₂O, mH₂O, mHg, g/cm2 , kg/cm2 , m, mm, cm, g/m³, kg/m³) | Installation: Mounts on a 50 mm (2-inch) pipe with a U-bolt. |
Application areas
Petroleum/Petrochemical/Chemical: Precise measurement of pressure and level in pipelines and storage tanks. Electricity/City Gas/Other Public Utilities: Places requiring high stability and high precision pressure and measurement.
Pulp/Paper: For environments requiring resistance to chemical and corrosive liquids in pressure measurement.
Steel/Non-ferrous Metals/Ceramics: For furnace pressure and negative pressure measurement in high-stability and high-precision environments.
Mechanical equipment/shipbuilding: Used in environments requiring stable measurements under strict control of pressure and other parameters.
