Technical Features:
HART7 Communication Protocol
Integrated Surge Protection
Built-in Dual-Button Quick Operation and Local Adjustment Function
Comprehensive Self-Diagnostic Function
Intelligent Static Pressure Compensation and Temperature Compensation
Performance Parameters:
Output: 4~20mA with HART Protocol Communication Function
Accuracy: Up to 0.1%
Sensor Type: Metal Capacitive Sensor, Single-Element Silicon Sensor
Measurement Range: 160Pa~20MPa
Process Interface: 1/4PT Internal Thread
Process Isolation Diaphragm: 316L, Hastelloy C-276, Tantalum, etc.
LED LCD Display
Mounting: Flat Plate Bracket and L-shaped Tube Mounting Bracket
