Technical Features:
HART Communication Protocol
Integrated Surge Protection
Built-in Dual-Button Quick Operation and Local Adjustment Function
Comprehensive Self-Diagnosis Function
Intelligent Static Pressure Compensation and Temperature Compensation
Performance Parameters:
Output: 4~20mA with HART Protocol Communication Function
Measurement Range: 100~10000mmH2O
Accuracy: Up to 0.2%
Sealing Fluids: Silicone Oil, Fluorinated Oil, Ethylene Glycol, etc.
Flange Types: Flat Flange, Raised Flange, Hybrid Type
Flange Standards: HG20592, HG20615
Wetted Materials: 316LSS, Hastelloy C-276, Tantalum, etc.
Capillary Tube: 1~15 meters optional
